In Stock Laser Rangefinder
Please contact us on availability and pricing.
Laser Rangefinder
Laser Rangefinder
| Product Model | VY-LIDAR-3000 |
| 1. Infrared Recognition Distance | Mid-Size Vehicle：≥2.8km； Standing Man：≥1km； |
| 2. Visible Light Recognition Distance | Mid-Size Vehicle：≥6.6km； Standing Man：≥3km； |
| 3. Laser Ranging | （1）Minimum Range：≤50m； |
| （2）Maximum Range：≥6km； | |
| （3）Precision：≤2m； | |
| （4）Accurate Rate：≥98%； | |
| （5）Repeat Frequency：≥0.5Hz； | |
| （6）Ranging Logic：Select to display the first or last target capability measured； | |
| （7）Laser Wavelength：Human eye safety band； | |
| 4. Diopter | -4SD～+4SD； |
| 5. Infrared FOV | ≥6.3°×5.0° |
| 6. Visible FOV | ≥3.2°×2.4° |
| 7.Focal Length | 50m～∞ |
| 8.Digital zoom | 1×~4× |
| 9.Visible light through fog | When visibility ≤4km, fog penetration ratio ≥1.5 |
| 10.Positioning Precision | ≤7m（CEP），≤10m（PE） |
| 11.Magnetic Azimuth | ≤0.5°（RMS） |
| 12.Target Positioning Accuracy： | at 2km of the distance，≤20m（CEP） |
| 16. IP Grade | IP67 |
| 17. Interface | （1）Data：USB； |
| （2）Video：PAL； | |
| （3）Communication：RS232； | |
| （4）Reserved picatinny rail interface。 | |
| 18. Operating Temperature： | -40℃～+55℃ |
